Molybdenum wire
Material: Pure molybdenum, Molybdenum alloy
Diameter: 0.02～200mm
Purity: ≥99.95%, Yttrium molybdenum, Lanthanum molybdenum etc
Standard: ASTM B387
Status: Stretching, Polishing
Shape: Straight, Coil
Density: 9.8～10.2g/cm3
Technology: Powder metallurgy
Size
|
Diameter (μm)
|
Weight (g/200mm)
|
200mm tolerance (mm)
|
Diameter tolerance (%)
|
||
|
20～30
|
0.65～1.47
|
±2.5
|
±3.0
|
—
|
—
|
|
30～40
|
1.47～2.61
|
±2.0
|
±3.0
|
—
|
—
|
|
40～200
|
2.61～256.2
|
±1.5
|
±3.0
|
—
|
—
|
Molybdenum tube
Material: Pure molybdenum, Molybdenum alloy
Size: OD: 30～500mm, WT: 0.3～30mm, Length: ≤4000mm
Purity: ≥99.95%, TZM, TZC, MoLa etc
Standard: ASTM B386
Status: Machining, Sintering, Welding, Stretching
Density: 9.8～10.2g/cm3
Technology: Powder metallurgy
Size(mm)
|
Product name
|
OD
|
WT
|
Length
|
|
Molybdenum tube
|
30～50
|
0.3～30
|
≤4000
|
|
50～100
|
0.5～15
|
||
|
100～150
|
1～15
|
||
|
150～300
|
1～20
|
||
|
300～400
|
1.5～30
|
||
|
400～500
|
2～30
|
Chemical composition
|
Molybdenum content
|
Other single element content
|
Total content of other elements
|
|
≥99.95%
|
≤0.01%
|
≤0.05%
|
|
Molybdenum alloy according to customer's requirements
|
||
Molybdenum crucible
Material: Pure molybdenum, Molybdenum alloy
Size: OD: 10～500mm, WT: 0.3～30mm, Height: 10～750mm
Purity: ≥99.95%, TZM, TZC, MoLa etc
Standard: ASTM B387, ASTM B386
Status: Sintering, Stamping, Welding
Density: 9.8～10.2g/cm3
Technology: Powder metallurgy
Size(mm)
|
Product name
|
OD
|
WT
|
Length
|
|
Molybdenum crucible
|
10～500
|
0.3～30
|
10～750
|
Chemical composition
|
Molybdenum content
|
Other single element content
|
Total content of other elements
|
|
≥99.95%
|
≤0.01%
|
≤0.05%
|
|
Molybdenum alloy according to customer's requirements
|
||
Molybdenum bar
Material: Pure molybdenum, Molybdenum alloy
Size: Diameter:0.8～200mm, Length:10～600mm
Purity: ≥99.95%, TZM, TZC, MoLa etc
Standard: ASTM B387
Status: Sintering, Rolling, Forging
Density: 9.8～10.2g/cm3
Technology: Powder metallurgy
Size (mm)
|
Product name
|
Diameter
|
Length
|
|
Forging bar
|
2.0～200
|
Customization
|
|
Stretching bar
|
0.8～3.0
|
Chemical composition
|
Molybdenum content
|
Other single element content
|
Total content of other elements
|
|
≥99.95%
|
≤0.01%
|
≤0.05%
|
|
Molybdenum alloy according to customer's requirements
|
||
Molybdenum sheet
Material: Pure molybdenum, Molybdenum alloy
Size: Thickness: 0.05～50mm, Width: 10～1000mm, Length: ≤1500mm
Purity: ≥99.95%, TZM, TZC, MoLa etc
Standard: ASTM B386
Status: Sintering, Rolling, Forging
Density: 9.8～10.2g/cm3
Technology: Powder metallurgy
Size (mm)
|
Product name
|
Thickness
|
Width
|
Length
|
|
Molybdenum crucible
|
0.05~50
|
10~1000
|
≤1500
|
